LAN / WAN Mini Module Fiber Optic PLC Splitter blockless 0.9mm with SC / UPC Connector

Name: LAN WAN Mini Module Fiber Optic PLC Splitter blockless 09mm with SC UPC Connector
Brand: YINGDA
Price: 1.1 USD

Quality LAN / WAN Mini Module Fiber Optic PLC Splitter blockless 0.9mm with SC / UPC Connector wholesale

Brand Name : YINGDA

Certification : ISO

Place of Origin : china

MOQ : 100PCS

Price : 1.1USD-4.58USD

Payment Terms : T/T or western Union

Supply Ability : 100,000pcs per month

Delivery Time : 5 working days after received your payment

Packaging Details : Packed in blister box or carton box,then in a shipping outer carton box.

Contact Now

Fiber Optic PLC splitter mini module/1:16 blockless PLC splitter 0.9mm with SC/UPC connector single mode

splitter coupler,white color cable

Unique Service:

SAMPLES for quality testing are available
6working days leading time if order quantity < 100pcs
Drawing, Specification, Test Report can be sent at any time if request
Quality complaint will handle in 24 hours by our After-sales Service Dept
1pcs per pack
OEM/ODM, customer LOGO or label available.

Features

Low Insertion loss

Low PDL

Compact Design

Good channel-to-channel uniformity

High Reliability and Stability

Application

FTTX Systems

PON Networks

CATV Links

Optical Signal Distribution

LAN/WAN system

Compliance

Telcordia GR-1209-CORE

Telcordia GR-1221-CORE

RoHS

Specification

Split ratio	1x2	1x4	1x8	1x16		1x32	1x64		1x128
Operating Wavelength(nm)	1260-1620nm
Fiber Type	G657A1 or customer specified
Insertion Loss (dB)P Grade	3.8	7.1	10.2		13.5	16.5	20.5		23.8
Insertion Loss (dB) S Grade	4.0	7.3	10.5		13.7	16.9	21		24.2
Loss Uniformity(dB)	0.4	0.6	0.8		1.2	1.5	2		2.5
Polarization Dependent Loss(dB)	0.2	0.2	0.2		0.25	0.3	0.35		0.4
Return Loss (dB)	55
Directivity (dB)	55
Wavelength Dependent Loss(dB)	0.3	0.3	0.3		0.5	0.5	0.5	0.5
Temperature Stability (-40- +85℃)(dB)	0.4	0.4	0.4		0.5	0.5	0.5	0.5
Operating Temperature	-40- +85℃
Storage Temperature	-40- +85℃

Split ratio

1x2

1x4

1x8

1x16

1x32

1x64

1x128

Mini-Module Dimension

(mm)

60*7*4

60*12*4

80*20*6

100*40*6

N/A

More product show:

LAN / WAN Mini Module Fiber Optic PLC Splitter blockless 0.9mm with SC / UPC Connector

Product Tags:

fbt coupler

plc splitter

LAN / WAN Mini Module Fiber Optic PLC Splitter blockless 0.9mm with SC / UPC Connector Images
